Type A transmitters are based on bridge resistance variation principle and the primary element is directly deposed on reaction mechanics by a silk screen-thick film process.
In this way the primary element can be very stable and offer the maximum protection because of monolithic ceramic block.
The innovative pressure sensor combines electronic precision with mechanical resistance for your complete safety in any conditions.
Low cost allows to use this sensor in many situation, above all in automation systems or as a supervisor for mechanical monitoring and process control.
For compatibility with most systems has ¼ gas male output fitting and is suitable for alimentary control because of the choice of material in contact with the fluid in accord with UL sanitation.
4-20mA analog output allows to get quite long distance link between sensor and remote control.
Temperature output allows to record temperature variation of device under control.
